Description
24 Port Managed Switch for Scalable Enterprise Networks
The HSP-IO-24GE4XS-C3PA+ L3 managed ethernet switch delivers high-capacity, reliable connectivity for medium-density networks. With 24 Gigabit Ethernet ports, PoE+ support, and flexible uplinks, this managed switch streamlines enterprise, BFSI, railway, and triple-play deployments.
This 24-port PoE switch enables centralized access control, secure operations, and efficient network management, ensuring smooth performance for staff, customers, and critical systems.
Physical Interface
L3 PoE+ Managed Switch
24×10/100/1000Mbps RJ45 Access Ports
4×1/10G SFP+ Uplink Ports
Upto 128 Gbps Switching Capacity
Upto 95.23 MPPS full Duplex Throughput
1x Console Port
1x RJ45 Management Port
L3 Features
OSPFv2/v3
RIPv1/v2
IPv4/IPv6 Static Routes
Inter VLAN
DHCP Server, Relay and Client
L2 Features
VLAN – MAC Based, Protocol Based, Voice VLAN, Private VLANs
L2 Loop avoidance (STP/RSTP/MSTP)
ERPS (ITU G.8032)
IGMP v1/v2/v3 Snooping
802.1q and QinQ
QoS – Classification, Marking, Policing, and Shaping
Design Parameters
0⁰C to +55⁰C Operating Temperature
1U Rack Mountable
Integrated Single AC Power Supply (100-240 VAC)
PoE
PoE Budget – 370W
Per Port PoE Configuration and Scheduling
Persistent PoE and Power Delay (to let the device boot)
Auto PoE Check and Reboot if Device does not Respond
Security
TACACS+ / RADIUS AAA
DHCP snooping, Dynamic ARP Inspection
Port Security, Sticky MAC, IP-MAC Binding
L2/L3/L4 ACL with Extended Features
Management
WEB GUI, CLI
SNMPv3, RMON, sFlow
Dual Stack (IPv4 and IPv6) Management
Ethernet OAM 802.3ah (CFM)
Download datasheet
