RUCKUS R550 Indoor Access Point Features
Wi-Fi capacity requirements in classrooms, office spaces, and medium-size venues are rising due to the increase in the number of Wi-Fi connected devices. An increase in bandwidth requirements for applications and an ever-growing assortment of IoT devices puts further strain on already stretched Wi-Fi networks.
The R550 access point (AP) with the latest Wi-Fi 6 (802.11 ax) technology delivers the ideal combination of increased capacity, improved coverage and affordability in dense environments. The R550 is our mid- range dual-band, dual-concurrent AP that supports four spatial streams (2×2:2 in 2.4GHz/5GHz). The R550 supports peak data rates of up to 1774 Mbps and efficiently manages up to 512 clients connections.
- Stunning Wi-Fi Performance – Mitigate interference and extend coverage with patented BeamFlex+™ adaptive antenna technology utilizing several directional antenna patterns
- Serve more devices – Connect more devices simultaneously with four MU-MIMO spatial streams and concurrent dual-band 2.4/5GHz radios while enhancing device performance
- Converged access point – Allow customers to eliminate siloed networks and unify Wi-Fi and IoT technologies into one single network by using built-in Bluetooth® Low Energy and Zigbee, and also expand to any future wireless technologies
- Automate Optimal Throughput – ChannelFly dynamic channel technology uses machine learning to automatically find the least congested channels. You always get the highest throughput the band can support
- Better Mesh Networking – Reduce expensive cabling, and complex mesh configurations by checking a box with SmartMesh wireless meshing technology to dynamically create self-forming, self-healing mesh networks
- More than Wi-Fi – Support services beyond Wi-Fi with RUCKUS IoT Suite, Cloudpath security and onboarding software, SPoT Wi-Fi locationing engine, and RUCKUS analytics
Specifications for RUCKUS R550 Indoor Access Point
![R550 | RUCKUS R550 Indoor Access Point [R550_Top]](https://www.ruckusnetworks.com/globalassets/digizuite/966262-r550-top.png/medium?mediaformatid=50103)
Product Classification
Regional Availability Asia | Australia/New Zealand | EMEA | Latin America | North America Product Type Indoor access point Product Brand RUCKUS® General Specifications
Antenna Patterns, per band 64 Antenna Gain Up to 3 dBi BeamFlex Yes ChannelFly Yes Concurrent Users 512 Controller Support RUCKUS Cloud™ | RUCKUS SmartZone | RUCKUS ZoneDirector | Standalone Ethernet Ports 2 x 1 GbE IoT Support IoT Onboard Number of Radios Dual-Radio PD-MRC Yes PHY Rate at 2.4 GHz, maximum 574 Mb/s PHY Rate at 5 GHz, maximum 1200 Mb/s Combined Max PHY Rate 1774 Mb/s Radio Chains and Streams 2×2:2 Rx Sensitivity at 2.4 GHz -97 dBm Rx Sensitivity at 5 GHz -97 dBm SmartMesh Yes USB USB 2.0 Venue Type Education | Hospitality | Office/Retail Venue Sub-Type Classroom | Hallways | Office Space Wi-Fi Bands Supported 2.4 GHz | 5 GHz Wi-Fi Generation Wi-Fi 6 Wi-Fi Interface Standard IEEE 802.11a/b/g/n/ac/ax Environmental Specifications
Operating Temperature 0 °C to +50 °C (+32 °F to +122 °F) Product Downloads and Links
